Jual CW Cable Gland Unibell. OSCG, Cable GLand OSNJ, Cable Gland Unibell, Cable Gland Brass, Cable Gland Nylon, Cable Gland Hawke, Cable Gland Metal PG dan Lain - lain.Cable Gland CW UnibellKami menjual Cable Gland Unibell type CW for Armoured Cable dengan jangkauan pengiriman ke seluruh indonesia.

Kabel Ties Hellermann Tyton InsulokKabel Ties sudah umum digunakan, baik itu untuk mengikat barang-barang elektronik dan lain sebagainya. Tali nilon ini sudah dalam posisi terikat maka biasanya kita akan kesulitan membukanya dan tak jarang kita melakukan jalan pintas yakni memotong atau merusaknya.

Jual Cable Gland CMP E1FWE1FW/M Mining, Internationally Approved, Explosive Atmosphere Cable Gland For all types Steel & Aluminium Wire Armoured cables• High quality durable materials• Wide sealing range for each cable gland size• Fully sequential, three step installation procedure• Reduces subjectivity of installations• Metal-to-metal armour clamping• Direct & remote installation• Displacement type flameproof inner seal• Controlled outer ‘load retention’ seal• Unique OSTG prevents overtightening• -60˚C to +130˚C • Permitted in Zone 1• Internationally marked, IECEx & ATEX• EMC testedTECHNICAL DATADesign Specification : BS 6121:Part 1:1989, IEC 62444, EN 62444Mechanical Classifications* : Impact = Level 8, Retention = Class DEnclosure Protection : IK10 to IEC 62262 (20 joules) Brass & Stainless Steel onlyElectrical Classifications* : Category BATEX Certificate : SIRA13ATEX1071XCode of Protection ^ : IM2 Ex d I Mb, Ex e I MbCompliance Standards : EN60079-0,1,7IECEx Certificate : IECEx SIR 13.0026X, IECEx SIM 14.0007XCode of Protection : Ex d I Mb, Ex e I MbCompliance Standards : IEC 60079-0,1,7Ingress Protection Rating : IP66 as standard (IP67, IP68 available upon request)**Cable Gland Material : Brass, Electroless Nickel Plated BrassSeal Material : CMP SOLO LSF Halogen Free Thermoset ElastomerCable Type : Single Wire Armour (SWA), Aluminium Wire Armour (AWA)Armour Clamping : Detachable Armour Cone & AnyWay Universal Clamping RingSealing Technique : CMP Inner Displacement Seal & Unique CMP ‘LRS’ TM Outer Load RetentionSeal Sealing Area(s) : Cable Inner Bedding & Outer Cable SheathKabel Metal dan Logam

Spesifikasi Name MAX ELECTRONIC LETTERING MACHINE LM-550A/PC Dimensions 295(W) x 293(D) x 94(H)mm Weight 2.4kg Printing method Thermal transfer method(300dpi) Display LCD dot matrix : 64 x 160Pixel (Backlit) Printing speed 40mm/s(Standard) 20mm/s(Low temperature mode) Maximum printing length Tube : 20m, Tape : 5m By multipule copy printing, maximum 30 copies. Upto Tube : 100m, Tape : 7m Maximum character input­­­­­­­­­­­ 5,000 characters per file Character size 1.3, 2, 3, 4, 6 mm height Usable tube size PVC Tube: Diameter 1.5mm ~ 8.0mm [for 1.5~2.0mm diameter tubes, the dedicated attacthment is required. Included with purchase]. Heat Shrinkable Tube: Diameter 2.0mm ~ 6.5mm. Usable tape size Width 5,9,12mm (MAX genuine tape) Tube cutting method Auto half cut, manual full cut Internal memory 250,000 characters(Maximum 50 files) External memory USB memory Interface USB 2.0 full speed Power supply DC 12V, 3.0A [Use only specified AC adapter(100V-240V) included in the package.] Power consumption 30W (max.) Operating environment 10 to 35 degrees celcius PC REQUIREMENTS For Windows 10/8.1/7 operating systems. Windows is a registered trademark of Microsoft Corperation(US) in U.S.A. or any other countries. Expendable supplies INK RIBBON CASE LM-RC500 (20pcs./ctn) ECONOMICAL INK RIBBON (10 ROLLS/BOX) LM-IR50B(BLACK) 110m/ROLL FOR HEAT SHRINK TUBE LM-IR50BP(BLACK)­110m/ROLL LM-IR50W(WHITE)­70m/ROLL Applications HIGH SPEED MARKING FOR: Swithch boards Panel boards Control panels Installation of telecoms and industrial machinery­ Related links Where to buy Download our brochure Owner's manual Cable Marker, Lettering Machine

CW CABLE GLANDSize 20 mm to 90 mm S & L Standard BS 6121,PART 1 ;1989 Application For indoor or outdoor use with all types of SWA Cable Function Provide for Environmental Seal in the Cable Outer Sheath,. Also provide mechanical cable retention & electrical continuity.Armore Material Brass BS 6121 Optional Threads METRIC, NPT, BSP, PG or as specified Finish Brass Finish, Nickel Finish, Chrome Finish or as specified Operating Temp. Standard seals -200 to +800 C Accessories Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, REducers, Adaptors, etc. as per the requirement  Gland SizeMetric EntryThread ‘C’Minimum ThreadLength ‘D’Under Armour Dia ‘A’ MaxOverall Dia ‘B’ MaxArmour Wire DiaAcross Corner Dia ‘E’ Max20S 20 108.0-11.812.9-17.20.9/1.2527.020L 20 1011.0-14.015.5-20.80.9/1.2531.025S 25 1012.0-17.017.5-24.01.25/1.6035.025L 25 1013.0-20.324.0-27.2 1.25/1.6039.032S 32 1017.0-24.025.0-31.01.60/2.0047.532L 32 1019.0-26.226.7-34.01.60/2.0047.540S 40 1523.0-30.031.0-38.51.60/2.0057.040L 40 1525.0-32.233.0-40.51.60/2.0057.050S 50 2031.5-38.239.5-46.82.00/2.5065.050L 50 2036.5-44.045.7-53.22.00/2.5073.063S 63 2042.5-50.052.1-59.02.5080.063L 63 2049.1-56.058.4-66.02.5089.075S 75 2054.5-62.064.8-72.02.5097.075L 75 2060.5-68.071.1-78.02.50105.090S 90 2066.0-76.077.0-86.02.50/3.15118.090L 90 2066.0-79.077.0-90.02.50/3.15118.9Dimensions in Millimeters Aksesoris Kabel Lainnya

Jual Cable Gland OSCG, Cable GLand OSNJ, Cable Gland Unibell, Cable Gland Brass, Cable Gland Nylon, Cable Gland Hawke, Cable Gland Metal PG dan Lain - lain.Hawke Cable Gland 501/453/RACGroup II Hazardous AreaFlameproof Exdb / Increased Safety Exeb / Dust Extb / Dual Certified ATEX - IECExAplikasiPenggunaan di luar ruangan atau dalam ruangan. Untuk penggunaan dengan armor kawat tunggal 'W', kawat jalinan 'X' dan elastomer besi baja 'Z' dan kabel terisolasi plastik.FiturMenyediakan penjepit armor menggunakan satu penjepit untuk semua jenis armor / braid.Menyediakan segel pada lapisan dalam kabel.Pilihan perlindungan Deluge tersedia, hubungi Hawke Technical Sales untuk rinciannya.Menyediakan retensi kabel dan asap dan asap rendah, segel halogen nol ke selubung luar kabel.Bahan & SelesaiKelenjar kabel 501/453 / RAC diproduksi di Kuningan (standar), Nikel Disepuh Kuningan, 316 Stainless Steel atau Aluminium. Entri NPT Kuningan dilapisi nikel sebagai standar.Data teknisExdb IIC Gb, Exeb IIC Gb, Extb IIIC DbSertifikat tidakBaseefa06ATEX0056X dan IECEx BAS 06.0013X.Cocok digunakan di:Zona 1, Zona 2, Zona 21, Zona 22 dan Kelompok Gas IIA, IIB dan IIC.Standar Konstruksi dan Uji:IEC / EN 60079-0, IEC / EN 60079-1, IEC / EN 60079-7 dan IEC / EN 60079-31.Ingress Protection:IP66, IP67 dan IP 68 * (30 meter selama 7 hari) ke IEC / EN 60529 dan NEMA 4X.* Prosedur pemasangan tambahan diperlukan.Deluge Protection ke:DTS01 (segel Deluge opsional).Rentang Suhu Operasional:-60 ° C sampai +100 ° CLembar Instruksi Perakitan:AI 302.Cable Gland

Flexible Metal Conduit ArrowtiteLiquid - Tight Flexible Metal Conduit - EF - InterlockedThe Product - Standard grade liquid - tight flexible conduitGalvanized steel strip, interlocked.Water - proof.High flexibility suitable to a wide range of application.PVC jacket in grey and black color.ApplicationSeals Out abrasives, alcohol, fumes, gases, dirt, oils, water and spray suitable fot the following potentials :Machine toolsSilo and plantHigh rise buildingsAir conditioning and ventilationComputer SecurityAksesoris Kabel Lainnya

Jual, Agent, Distributor Pipa Conduit Jis Dan Ansi, Panasonic Conduit Pipe :1. Jis Standar : Threadless, Threaded2. Ansi Standar : Emt, Rigid Steel Conduit ( Rsc)3. Accesories : Coupling, Elbow, Locknuts, Bushing, Clamp, Circular Surface Box, Reducer, Tee Box, EtcAgent / Distributor Pipa Metal ConduitType :Emt ( Polos )Rigid ( Drat )Standart :JisAnsiFinishing :Electro GalvanizedHot Dipped GalvanizedAccessories :CouplingConnectorElbow Normal BendCircular Surface BoxUniversal FittingsBushingLocknutClampRace WayDllAksesoris Kabel Lainnya

Jual Kabel Lug BimetalBimetal Lug ( Skun Bimetal ) adalah sepatu kabel yang terbuat dari bahan tembaga yang disambung dengan alumunium dengan sistim pergesekan tanpa bahan pembantu sehingga terjadi sambungan yang sempurna ( bersenyawa ). Gunanya untuk terminal kabel alumunium yang akan dihubungkan dengan komponen tembaga.Untuk mencegah oksidasi alumunium tersebut diberi minyak grease.

Jual Cable Gland OSCG, Cable GLand OSNJ, Cable Gland Unibell, Cable Gland Brass, Cable Gland Nylon, Cable Gland Hawke, Cable Gland Metal PG dan Lain - lain.OSCG Cabl Gland E1FX / E1WF/E1UFAPPLICATION* Flameproof & Increased Safety. * For use with braid armoured / steel tape armoured cable. * For Zone1 & Zone2 in hazardous area. * Double compression for outer / inner jacket of cable. * Inspectable armoured clamping cable gland. * Outdoor type.* In accordance with EN 50014 : 1997 + A1 : 1999 + A2 : 1999* CENELEC EN 50018 : 2000, CENELEC EN 50019 : 2000,* And CENELEC EN 50281-1-1 : 1998 + A1 : 2002 PROTACTION* II GD EExd IIC / EExe II* IP 67 (EN 60529) * Allowable temperature on the elastomeric sealing ring :   100°C(ATEX), 120°C(GOST R/FSETAN). MATERIALS* Brass & Nickel coated / Stainless Steel. APPROVAL* ISO 9001 : 2000* According to BS, IEC & CENELEC. * Suitable for use in Zone1, Zone2. * Suitable for use in Gas Groups IIA, IIB and IIC.  ACCESSORIES* Lock Nut, Sealing Washer, Earth-Tag, Shroud. * Lead Sheath Washer, Serrated Washer, Stopping Plug. * Reducer, Adaptor. ATEX Cable Gland Ordering* Part No / Thread size.    e.g. OSXF-101 / M16         OSXF-101 / NPT 1/2"All dimensions in millimeters (except of type NPT) Option : Thread 18mm.  CERTIFICATION* ATEX NEMKO (02ATEX 501X) * SHELL  Approval* GOST-R/FSETN Premit for Hazardous area.Cable Gland
